Description
group_workTechnical Specifications
-
5 IN 1 CONVERTERYES
-
ACOUSTIC JACKET ON COMPRESSORYES
-
AIR FLOW VOLUME (DRY CFM/DRY CMH)675/1150
-
COMPRESSOR TYPEROTARY
-
COMPRESSOR WARRANTY10 YEAR
-
CONDENSER FINSCOPPER CONDENSER WITH ANTI CORROSIVE BLUE FINS
-
COPPER PIPE (m)3
-
DISPLAY IN IDUHIDDEN DISPLAY
-
ELECTRICITY CONSUMPTION ( 1600 HOURS ) UNITS PER YEAR980.37
-
EVAPORATOR FINSHYDROPHILIC BLUE FINS
-
EXPANSION DEVICE IN ODUCAPILLARY
-
FILTER CONFIGURATIONANTI DUST FILTER
-
FRONT PANEL COLOUR (IVY PATTERN)BEIGE | BLUE
-
FRONT PANEL COLOUR (STRIP)WHITE
-
GROSS IDU DIMENSION (W X H X D) cm105.4 x 37.2 x 30.1
-
GROSS ODU DIMENSION ( W X H X D) cm82.4 x 56.7 x 34.6
-
GROSS WEIGHT IDU (kg)13
-
GROSS WEIGHT ODU (kg)29.2
-
HORIZONTAL LOUVERAUTO
-
i-SenseYES
-
INPUT POWER SUPPLYINDOOR UNIT
-
INTER CONNECTING CABLE (m)3.5
-
ISEER (STAR RATING)3.95 (3 Star)
-
LIQUID TUBE SIZE OUTER DIAMETER INCHES (mm)1/4" (6)
-
MAX AMBIENT TEMP (COOLING)?52
-
MAX COOLING CAPACITY (RATED COOLING CAPACITY)5250w (5000w)
-
MAX PIPING CAPABILITY TOTAL (m)15
-
MAX PIPING CAPABILITY VERTICAL (m)7
-
MODESCOOL/AUTO/DRY/FAN/SLEEP/TURBO
-
NET IDU DIMENSION (W X H X D) cm98.2 x 30 x 24.1
-
NET ODU DIMENSION ( W X H X D) cm78 x 54.5 x 32
-
NET WEIGHT IDU (kg)11.5
-
NET WEIGHT ODU (kg)26
-
NOISE LEVEL INDOOR (HIGH/ MEDIUM / LOW) in dB(A)48/44/40
-
NOISE LEVEL OUTDOOR in dB(A)58
-
POWER INPUT IN WATTS1650
-
RATED CURRENT (AMP)7.6
-
RATED VOLTAGE / FREQUENCY / PHASE230V/50Hz/1Phase
-
REFRIGERANTR32
-
REFRIGERANT ADDITIONAL CHARGE BEYOND 4m (g/m)15
-
SUCTION TUBE SIZE OUTER DIAMETER INCHES (mm)1/2" (12)
-
VERTICAL LOUVERAUTO
