Description
Technical Specifications
-
5 IN 1 CONVERTERYES
-
ACOUSTIC JACKET ON COMPRESSORYES
-
AIR FLOW VOLUME (DRY CFM/DRY CMH)818/1390
-
ANTI FREEZEYES
-
AUTO RESTART WITH MEMORY FUNCTIONYES
-
CLOCKYES
-
COMPRESSOR TYPEROTARY
-
COMPRESSOR WARRANTY10 YEAR
-
CONDENSER FINSCOPPER CONDENSER WITH ANTI CORROSIVE BLUE FINS
-
COPPER PIPE (m)2.95
-
DISPLAY IN IDUHIDDEN DISPLAY
-
ELECTRICITY CONSUMPTION ( 1600 HOURS ) UNITS PER YEAR1330.81
-
EVAPORATOR FINSHYDROPHILIC BLUE FINS
-
EXPANSION DEVICE IN ODUCAPILLARY
-
FILTER CONFIGURATIONANTI DUST + ACTIVE CARBON + ANTI VIRAL NANO COATED
-
FRONT PANEL COLOUR (STRIP)WHITE (GOLD)
-
GROSS IDU DIMENSION (W X H X D) cm119 x 40 x 32
-
GROSS ODU DIMENSION ( W X H X D) cm90.5 x 59.0 x 37.5
-
GROSS WEIGHT IDU (kg)18
-
GROSS WEIGHT ODU (kg)31.4
-
HORIZONTAL LOUVERAUTO
-
HYGIENE+ / BLOW (SELF CLEAN)YES
-
i-SenseYES
-
INPUT POWER SUPPLYINDOOR UNIT
-
INTER CONNECTING CABLE (m)3.5
-
ISEER (STAR RATING)4.1 (3 Star)
-
LIQUID TUBE SIZE OUTER DIAMETER INCHES (mm)1/4" (6)
-
LOCKYES
-
MAX AMBIENT TEMP (COOLING)?52
-
MAX COOLING CAPACITY (RATED COOLING CAPACITY)7420w (7050w)
-
MAX PIPING CAPABILITY TOTAL (m)15
-
MAX PIPING CAPABILITY VERTICAL (m)10
-
MODESCOOL/DRY/FAN/SLEEP/TURBO
-
NET IDU DIMENSION (W X H X D) cm110 x 33 x 25
-
NET ODU DIMENSION ( W X H X D) cm78.1 x 55.7 x 28.1
-
NET WEIGHT IDU (kg)14
-
NET WEIGHT ODU (kg)27.4
-
NOISE LEVEL INDOOR (HIGH/ MEDIUM / LOW) in dB(A)46/40/38
-
NOISE LEVEL OUTDOOR in dB(A)60
-
POWER INPUT IN WATTS2225
-
RATED CURRENT (AMP)10.2
-
RATED VOLTAGE / FREQUENCY / PHASE230V/50Hz/1Phase
-
REFRIGERANTR32
-
REFRIGERANT ADDITIONAL CHARGE BEYOND 4m (g/m)20
-
SELF DIAGNOSIS (ERROR CODES)YES
-
SUCTION TUBE SIZE OUTER DIAMETER INCHES (mm)1/2" (12)
-
TIMER ON / OFFYES
-
TONNAGE CLASSIFICATION2.5 Tr.
